    1000 Cd/M2 High Brightness LCD Module 640x480 TFT Display 3.5 Inch

    Ask Lasest Price
    Brand Name : AISON
    Model Number : Z035VG06
    Certification : ISO9001 / ISO14000/ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 200k/month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    1000 Cd/M2 High Brightness LCD Module 640x480 TFT Display 3.5 Inch

    3.5 inch High Brightness RGB TFT LCD Display Module 640x480 Resolution


    Display General Description
    Z035VG06 is 640x480 pixels 3.5 inch IPS tft lcd display with driver NV3052C,RGB interface.It's optional capacitive touch panel with controller, resistive touch panel,FPC connector,superior display quality,full view angle.Easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM.
    It provides excellent visibility in outdoor sunlight or challenging industrial environments.
    The IPS panel has the advantage of wide viewing angles of Left:80 / Right:80 / Up:80 / Down:80 degrees (typical). Z035VG06 can operate at temperatures from -20℃ to +70℃, and its storage temperatures range from -30℃ to +80℃. .

    General Data

    Model Name3.5 inch 340x480 TFT LCD
    Resolution640x480
    Model Size (W*H*T)76.90*63.9*3.26mm
    Display Area (W*H)70.08 x 52.56mm
    InterfaceRGB
    Display ModeNormally Black,Transmissive
    ViewingIPS
    Brightness1000 cd/m2
    Pin number54 pin
    Driver ICNV3052C
    Operating temperatures-20 to 70
    Storage temperatures-30 to 80


    Drawing

    Product Details

    1000 Cd/M2 High Brightness LCD Module 640x480 TFT Display 3.5 Inch


    TFT Applications

    Recommended Applications: Outdoor Measurement Instruments & Industrial Equipment: High brightness and stable display performance make this module ideal for use in bright sunlight or complex environments, ensuring long-lasting readability.


    Portable Testing Equipment: Compact and lightweight, this module is perfect for portable testing needs, offering reliable display performance for fieldwork and routine operations.


    1000 Cd/M2 High Brightness LCD Module 640x480 TFT Display 3.5 Inch
