Introducing the Z156FH03-CT: a high-performance 15.6-inch
high-resolution TFT LCD display module designed to deliver
exceptional visual clarity and functionality. This advanced display
module features a resolution of 1920x1080 pixels, supported by PCAP
touch technology, ensuring precise and responsive interaction.
The module is equipped with a built-in TC2055G driver IC, enabling
seamless integration and operation via the LVDS interface.
Measuring 384.16 x 253.58 mm in outline dimensions, with an active
area of 344.16 x 193.59 mm, this display leverages IPS technology
to provide an impressive 85-degree viewing angle in all directions
(left, right, up, down), ensuring optimal visibility from any
angle.
Boasting a high contrast ratio of 800:1 (typical) and a brightness
of 1000 nits (typical), this module delivers vibrant and vivid
visuals, enhancing the overall user experience. The integrated
projected capacitive touch panel (PCAP) with ILI2511 IC supports
USB and I2C interfaces, along with 10-point touch functionality,
further elevating its usability and versatility.
Engineered for reliability and durability, the Z156FH03-CT operates
within a power voltage range of 3.0V to 3.6V (typical: 3.3V) and is
designed to withstand a wide range of environmental conditions. Its
operating temperature range of -20°C to +70°C, and storage
temperature range of -30°C to +80°C, makes it ideal for various
applications, including industrial machinery, HMI (Human-Machine
Interface) systems, POS (Point of Sale) terminals, and outdoor
vending systems.
With its robust performance, wide viewing angles, and advanced
touch capabilities, the Z156FH03-CT is a reliable and high-quality
solution for demanding applications.
