    4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin

    Ask Lasest Price
    Brand Name : AISON
    Model Number : Z046HD01
    Certification : ISO9001 / ISO14000/ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 100k/month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin

    4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin


    General Description

    Z046HD01 is a portrait mode 4.6 inch stretched bar type TFT LCD with a resolution of 320X960pixels.Its interface is 2 Lane MIPI with a contrast Ratio 1200:1.


    The module operates in temperatures ranging from -20℃ to +70℃, and can be stored in temperatures from -30℃ to +80℃. This bar type TFT module is ideal for use in electronic door locks, massage chair control panels, and other devices that require a stretched display screen.


    General Data

    Model Name4.6 inch Stretched Bar LCD Display
    Resolution320x960
    Model Size (W*H*T)mm41.57*118.8*2.5 mm
    Display Area (W*H)mm36.768 x 110.304 mm
    InterfaceMIPI
    Display ModeNormally Black,Transmissive
    ViewingIPS
    Brightness300 cd/m2
    Pin number30 pin
    Contrast Ratio
    1200:1
    Operating temperatures-20 to 70 degree
    Storage temperatures-30 to 80 degree

    Drawing



    Product Details

    4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin4.6 Inch 320x960 Bar Type TFT LCD Display with MIPI Interface 30 Pin


    TFT Applications:

    The module operates in temperatures ranging from -20℃ to +70℃, and can be stored in temperatures from -30℃ to +80℃. With the demand for custom projects going up every day, the bar type TFT market is growing correspondingly. And our bar type TFT solution can be perfectly used in many applications like industrial, automotive, medical, home appliance and maritime, etc. This bar type TFT module is ideal for use in electronic door locks, massage chair control panels, and other devices that require a stretched display screen.
